The AMD Ryzen 5 7500X3D is a gaming-focused desktop processor on the AM5 platform, built on AMD’s Zen 4 architecture with 3D V-Cache technology. It delivers strong gaming performance with efficient power use, making it a compelling choice for mid-range builds.
Key Features:
6 cores / 12 threads
3D V-Cache for enhanced game performance
65 W TDP (energy efficient)
DDR5 memory support and PCIe 5.0 connectivity
Integrated AMD Radeon graphics
AM5 socket
Full Technical Specifications:
Architecture & Design
CPU Architecture: AMD Zen 4
Process: 5 nm (CPU cores) + 6 nm (I/O)
Socket: AM5
Cores / Threads: 6 / 12
Performance
Base Clock: 4.0 GHz
Boost Clock: Up to 4.5 GHz
L1 Cache: 384 KB
L2 Cache: 6 MB
L3 Cache: 96 MB (3D V-Cache)
Thermal Design Power (TDP): 65 W
Max Operating Temperature: 89 °C
Memory & Storage
Memory Type: DDR5
Max Memory Speed: 5200 MT/s
Memory Channels: Dual-channel
Max Memory Capacity: 128 GB
Supports NVMe storage and RAID 0/1/10
Connectivity
PCI Express Version: 5.0
PCIe Lanes: Up to 28
Integrated Graphics
GPU: AMD Radeon Graphics
GPU Cores: 2
GPU Frequency: Up to 2200 MHz
Additional Features
Precision Boost Overdrive (PBO) & Curve Optimizer support
No cooler included in the box
Compatible with chipset families: A620, B650, X670
