Motherboard ASUS ROG STRIX B850-I GAMING WIFI – AM5 Socket - DDR5 Support - WiFi 7 - Bluetooth 5.4 - Mini-ITX Form Factor

The ASUS ROG STRIX B850-I GAMING WIFI is a compact yet powerful Mini-ITX motherboard built for high-performance gaming setups using the latest AMD Ryzen™ 8000 and 7000 Series processors. With support for WiFi 7, DDR5 memory, PCIe 5.0, and USB 4.0, this board is designed to offer cutting-edge connectivity and peak overclocking potential in a small form factor.

Key Features:
• Mini-ITX form factor – ideal for compact builds
• Compatible with AMD Ryzen™ 8000 / 7000 Series CPUs (AM5 socket)
• Next-gen connectivity with WiFi 7 and Bluetooth 5.4
• PCIe 5.0 x16 graphics support
• DDR5 memory support up to 8000+ MT/s (OC)
• Robust power delivery with 10+2+1 Power Stage Design
• Two M.2 PCIe 5.0 & 4.0 slots for ultra-fast NVMe storage
• SupremeFX audio with ALC4080 codec and Savitech amplifier
• High-performance cooling with VRM heatsinks and multiple fan headers
• USB 4.0 Type-C®, USB 3.2 Gen 2x2, HDMI® 2.1, and DisplayPort™ 1.4

Technical Specifications:

• Form Factor: Mini-ITX (17 cm x 17 cm)
• CPU Socket: AM5
• Chipset: AMD B850
• Supported CPUs: AMD Ryzen™ 8000 & 7000 Series
• Memory Support:
– 2 x DIMM, up to 96GB DDR5
– Dual-channel architecture
– Up to 8000+ MT/s (OC)

• Expansion Slots:
– 1 x PCIe 5.0 x16 slot

• Storage:
– 2 x M.2 slots
• 1 x M.2 2280 (PCIe 5.0 x4)
• 1 x M.2 2280 (PCIe 4.0 x4)
– 2 x SATA 6Gb/s ports

• Networking:
– Intel® WiFi 7
– Bluetooth® 5.4
– 1 x Intel® 2.5Gb Ethernet

• USB Ports:
– Rear I/O:
• 1 x USB 4.0 Type-C®
• 2 x USB 3.2 Gen 2 Type-A
• 4 x USB 3.2 Gen 1 Type-A
– Internal Headers:
• USB 3.2 Gen 1, USB 2.0

• Audio:
– SupremeFX ALC4080 Codec
– Savitech amplifier
– High-quality audio capacitors

• Display Outputs:
– 1 x HDMI 2.1
– 1 x DisplayPort 1.4

• Internal Connectors:
– Multiple 4-pin fan headers
– RGB headers (ARGB + RGB)
– Front panel USB Type-C header

• Other Features:
– Pre-mounted I/O shield
– BIOS FlashBack™ button
– Q-LED diagnostic indicators
– Reinforced PCIe slot (SafeSlot)
– AI Cooling & AI Networking support

• Operating System Support:
– Windows 11 / Windows 10 64-bit
