ASUS MOTHERBOARD ROG STRIX Z890-E GAMING WIFI D5 WiFi-7AURA - LGA 1851

The ASUS ROG STRIX Z890-E GAMING WIFI is a next-generation ATX motherboard designed for elite gaming, overclocking, and high-end PC builds. Built on the latest Intel Z890 chipset with the new LGA 1851 socket, it supports 14th and upcoming Intel desktop CPUs, blazing-fast DDR5 memory, WiFi 7, PCIe 5.0, and the signature ROG features gamers and enthusiasts expect.

Key Features:

• Supports Intel 14th Gen & next-gen processors with LGA 1851 socket

• Z890 chipset with high-end power delivery for overclocking

• DDR5 memory support up to 192GB (OC)

• Integrated WiFi 7 for ultra-fast wireless connectivity

• PCIe 5.0 for GPUs and M.2 storage

• Robust VRM cooling with stylish AURA RGB lighting

• AI-based tuning: AI Overclocking, AI Cooling II

• SupremeFX audio and high-performance networking

Technical Specifications:

Model Number: 90MB1IM0-M0EAY0
Series: ROG STRIX Z890-E GAMING WIFI
Form Factor: ATX

CPU Compatibility:

• Socket: LGA 1851

• Supports 14th Gen Intel Core and future Intel processors

• Chipset: Intel Z890

Memory:

• Memory Type: DDR5

• Max Capacity: Up to 192GB

• Memory Slots: 4 × DIMM

• Supported Speeds: Up to 8000+ MHz (OC)

• Dual-channel architecture

• Intel XMP 3.0 support

Expansion Slots:

• 1 × PCIe 5.0 x16 (reinforced for GPU)

• 1 × PCIe 4.0 x16

• 2 × PCIe 3.0 x1

Storage:

• M.2 Slots:

  • 1 × PCIe 5.0 x4

  • 3 × PCIe 4.0 x4

• SATA: 4 × SATA 6Gb/s ports

• RAID support for both M.2 and SATA

Networking & Wireless:

• LAN: Intel 2.5G Ethernet

• Wireless: Integrated WiFi 7 (802.11be)

• Bluetooth: Version 5.4

Audio:

• ROG SupremeFX 7.1 Surround Sound

• High-definition audio with premium capacitors

• Audio shielding and impedance sensing

USB Connectivity:

• Rear I/O:

  • 1 × USB 3.2 Gen 2x2 Type-C

  • 4 × USB 3.2 Gen 2

  • 4 × USB 2.0

• Internal headers:

  • USB 3.2 Gen 1, Gen 2, USB-C, and USB 2.0

Cooling & Aesthetics:

• VRM heatsinks with embedded fan

• Multiple PWM fan headers

• AURA Sync RGB lighting (addressable RGB headers)

• Reinforced steel backplate

AI Features:

• AI Overclocking

• AI Cooling II

• AI Networking (GameFirst VI)

BIOS & Utilities:

• UEFI BIOS with EZ and Advanced Modes

• ASUS Armoury Crate

• BIOS FlashBack™ & Clear CMOS

Power Design:

• Robust 18+2 phase power delivery

• ProCool II power connectors

• Premium alloy chokes and capacitors
